제품 상세보기

Ethernet I/O 모듈

추가 큰 이미지 보기

ET-7000/ET-7200 시리즈

제품명: ET-7000/ET-7200 시리즈

용도: 디지털 I/O 모듈 (선택가이드)

특성: Ethernet 입출력 모듈

제조사: ICPDAS(대만)

모델명		DI			DO
디지털 입출력 (DC Digital I/O)
모델명		채널	타입	Sink/Source	채널	타입	Sink/Source	최대 부하 전류 @ 25 °C
ET-7042	ET-7242	–	–	–	16	Open Collector	Sink	100 mA/channel
ET-7042-UT	ET-7242-UT
PET-7042	PET-7242
ET-7044	ET-7244	8	Wet	Sink, Source	8	Open Collector	Sink	300 mA/channel
PET-7044	PET-7244	8	Wet	Sink, Source	8	Open Collector	Sink	300 mA/channel
–	ET-7245	–	–	–	16	Open Source	Source	600 mA/channel
–	PET-7245	–	–	–	16	Open Source	Source	600 mA/channel
ET-7050	ET-7250A	12	Wet	Sink, Source	6	Open Collector	Sink	100 mA/channel
PET-7050	PET-7250A	12	Wet	Sink, Source	6	Open Collector	Sink	100 mA/channel
ET-7051	ET-7251	16	Wet	Sink, Source	–	–	–	–
PET-7051	PET-7251	16	Wet	Sink, Source	–	–	–	–
ET-7052	ET-7252	8	Wet	Sink, Source	8	Open Collector	Source	650 mA/channel
PET-7052	PET-7252	8	Wet	Sink, Source	8	Open Collector	Source	650 mA/channel
ET-7053	ET-7253	16	Dry	Source	–	–	–	–
PET-7053	PET-7253	16	Dry	Source	–	–	–	–
–	ET-7255	8	Dry, Wet	Sink	8	Open Collector	Source	650 mA/channel
–	PET-7255	8	Dry, Wet	Sink	8	Open Collector	Source	650 mA/channel

모델명		DI
디지털 입력 (AC/DC Digital Input)
모델명		채널	타입	Sink/Source
–	ET-7258	8	Wet	Sink, Source
–	PET-7258	8
–	ET-7258M-16	16
–	PET-7258M-16	16
–	ET-7259	8	Wet	Sink, Source
–	PET-7259	8
–	ET-7259M-16	16
–	PET-7259M-16	16

모델명		Relay Output				DI
릴레이 출력 및 디지털 입력 (Relay Output & Digital Input)
모델명		채널	릴레이	타입	최대 부하 전류 @ 25°C	채널	타입	Sink/Source
ET-7060	ET-7260	6	Power Relay	Form A (SPST N.O.)	5.0 A/channel	6	Wet	Sink, Source
PET-7060	PET-7260	6	Power Relay	Form A (SPST N.O.)	5.0 A/channel	6	Wet	Sink, Source
–	ET-7261	11	Power Relay	Form A (SPST N.O.)	5.0 A/channel	–	–	–
–	PET-7261	11	Power Relay	Form A (SPST N.O.)	5.0 A/channel	–	–	–
ET-7065	–	6	PhotoMOS Relay	Form A (SPST N.O.)	1.0 A/channel	6	Wet	Sink, Source
PET-7065	–	6	PhotoMOS Relay	Form A (SPST N.O.)	1.0 A/channel	6	Wet	Sink, Source
ET-7066	–	8	PhotoMOS Relay	Form A (SPST N.O.)	1.0 A/channel	–	–	–
PET-7066	–	8	PhotoMOS Relay	Form A (SPST N.O.)	1.0 A/channel	–	–	–
ET-7067	ET-7267	8	Power Relay	Form A (SPST N.O.)	5.0 A/channel	–	–	–
PET-7067	PET-7267	8	Power Relay	Form A (SPST N.O.)	5.0 A/channel	–	–	–
